| Backhoe |
|
Bucket Dig Force |
11,212 lbs (5,086 kg)
|
|
Bucket Dig Force |
11,212 lbs (5,086 kg)
|
|
Bucket Dig Force - Extended |
11,212 lbs (5,086 kg)
|
|
Bucket Dig Force - Extended |
11,212 lbs (5,086 kg)
|
|
Dig Depth |
14 ft (4 m)
|
|
Dig Depth |
14 ft (4 m)
|
|
Dig Depth - Extended |
18 ft (6 m)
|
|
Dig Depth - Extended |
18 ft (6 m)
|
|
Load Height - Extended |
13 ft (4 m)
|
|
Load Height - Extended |
13 ft (4 m)
|
|
Reach at Load Height - Extended |
12 ft (4 m)
|
|
Reach at Load Height - Extended |
12 ft (4 m)
|
|
Reach From Swivel |
18 ft (5 m)
|
|
Reach From Swivel |
18 ft (5 m)
|
|
Reach From Swivel - Extended |
22 ft (7 m)
|
|
Reach From Swivel - Extended |
22 ft (7 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Height to Top of Suspended Cab |
9 ft (3 m)
|
|
Height to Top of Suspended Cab |
9 ft (3 m)
|
|
Transport Length |
23 ft (7 m)
|
|
Transport Length |
23 ft (7 m)
|
|
Transport Width |
7 ft (2 m)
|
|
Transport Width |
7 ft (2 m)
|
|
Wheelbase |
7 ft (2 m)
|
|
Wheelbase |
7 ft (2 m)
|
| Engine |
|
Aspiration |
Natural |
|
Aspiration |
turbocharged |
|
Displacement |
272 cu in (4,457 cu cm)
|
|
Displacement |
272 cu in (4,457 cu cm)
|
|
Engine Model |
Family III 445/M2 Tier II certified |
|
Engine Model |
Family III 445T/M2 Tier II certified |
|
Gross Power |
80 hp (60 kw)
|
|
Gross Power |
85 hp (63 kw)
|
|
Net Max Torque |
231 lbs ft (313 nm)
|
|
Net Max Torque |
246 lbs ft (334 nm)
|
|
Net Power |
76 hp (57 kw)
|
|
Net Power |
80 hp (60 kw)
|
|
Net Torque Rise |
0 |
|
Net Torque Rise |
0 |
|
Number of Cylinders |
4 |
|
Number of Cylinders |
4 |
|
Power Measured @ |
2,200 rpm |
|
Power Measured @ |
2,200 rpm |
|
Torque Measured @ |
1,400 rpm |
|
Torque Measured @ |
1,400 rpm |
| General Specifications |
|
4th Gear Fwd mph (kmh) (Since 2004)
|
25 (40.2) |
|
Breakout Force lbs (kgs) (Since 2004)
|
9,164 lb/f (40,761N) |
|
Digging Depth ft (m) (Since 2004)
|
14.3 (4.34) |
|
Lift Capacity lbs (kgs) (Since 2004)
|
6,182 (2,804) |
|
Loading Height ft (m) (Since 2004)
|
11.2 (3.4) |
|
Operating Weight lbs (kg) (Since 2004)
|
13,359 (6,060) |
|
SAE Net hp (kW) (Since 2004)
|
73 (54) |
| Hydraulic System |
|
Pump Flow Capacity |
29 gpm (108 lpm)
|
|
Pump Flow Capacity |
29 gpm (108 lpm)
|
|
Pump Type |
gear-type transmission driven |
|
Pump Type |
gear-type transmission driven |
|
Relief Valve Pressure |
3,050 psi |
|
Relief Valve Pressure |
3,050 psi |
| Loader |
|
Bucket Breakout Force |
9,164 lbs (4,157 kg)
|
|
Bucket Breakout Force |
9,164 lbs (4,157 kg)
|
|
Bucket Capacity |
1 cu yd (1 cu m)
|
|
Bucket Capacity |
1 cu yd (1 cu m)
|
|
Bucket Width |
82 in (208 cm)
|
|
Bucket Width |
82 in (208 cm)
|
|
Clearance at Max Dump Height |
9 ft (3 m)
|
|
Clearance at Max Dump Height |
9 ft (3 m)
|
|
Dig Depth |
8 in (20 cm)
|
|
Dig Depth |
8 in (20 cm)
|
|
Reach at Max Dump Height |
28 ft (9 m)
|
|
Reach at Max Dump Height |
2 ft (1 m)
|
| Operating Specifications |
|
Alternator Supplied Amperage |
90 amps |
|
Alternator Supplied Amperage |
90 amps |
|
Cooling System Fluid Capacity |
5 gal (17 l)
|
|
Cooling System Fluid Capacity |
5 gal (17 l)
|
|
Front Axle Fluid Capacity |
2 gal (6 l)
|
|
Front Axle Fluid Capacity |
2 gal (6 l)
|
|
Fuel Capacity |
31 gal (119 l)
|
|
Fuel Capacity |
31 gal (119 l)
|
|
Hydraulic System Fluid Capacity |
28 gal (106 l)
|
|
Hydraulic System Fluid Capacity |
28 gal (106 l)
|
|
Max Weight |
16,510 lbs (7,489 kg)
|
|
Max Weight |
16,510 lbs (7,489 kg)
|
|
Oil System Fluid Capacity |
4 gal (14 l)
|
|
Oil System Fluid Capacity |
4 gal (14 l)
|
|
Operating Voltage |
12 volts |
|
Operating Voltage |
12 volts |
|
Operating Weight 2wd |
13,359 lbs (6,060 kg)
|
|
Operating Weight 2wd |
13,359 lbs (6,060 kg)
|
|
Rear Axle Fluid Capacity |
4 gal (14 l)
|
|
Rear Axle Fluid Capacity |
4 gal (14 l)
|
|
Tire Size Front - 2wd / 4wd |
11Lx16.1/12x16.5 |
|
Tire Size Front - 2wd / 4wd |
11Lx16.1/12x16.5 |
|
Transmission Fluid Capacity |
6 gal (21 l)
|
|
Transmission Fluid Capacity |
6 gal (21 l)
|
|
Turning Radius |
11 ft (3 m)
|
|
Turning Radius |
21 ft (6 m)
|
| Tires |
|
Rear Tires Size |
17.5Lx24/19.5Lx24 |
|
Rear Tires Size |
17.5Lx24/19.5Lx24 |
| Transmission |
|
Max Speed |
25 mph (39 kph)
|
|
Max Speed |
25 mph (39 kph)
|
|
Max Speed - Reverse |
30 mph (48 kph)
|
|
Max Speed - Reverse |
30 mph (48 kph)
|
|
Number of Forward Gears |
4 |
|
Number of Forward Gears |
4 |
|
Number of Reverse Gears |
4 |
|
Number of Reverse Gears |
4 |
|
Transmission Type |
4-speed synchromesh with hydraulically actuated clutches |
|
Transmission Type |
4-speed synchromesh with hydraulically actuated clutches |
