2025 Case 850M For Sale in Miami, FL

Name: 2025 Case 850M
Brand: Case
SKU: 84747347
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: Call for Price

Case Power & Equipment

Case Power & Equipment Dealer Info

Case Power & Equipment Website

Click here to email Case Power & Equipment.

Click for Phone Number

Machine Info:

Stock Number:	HBZN850MVRAC02071
Machine Location:	MIAMI, FL
More Information:	https://casepowered.com/inventory/dozers+-+crawler/2025-case-850m-fort+myers-fl-69723b8c30e559a6b6095954/

Description:

2025 CASE, 850M Dozers - Crawler, ***NEW MACHINE*** Call for pricing 850M Also available at other CPEFL locations, call for info With best-in-class drawbar pull of 42,813 lbs and best-in-class power of 112 hp, no other dozer of this size puts more power at your control. And as one of industrys first dozers to have fuel-efficient SCR technology built in, youll be able to do more in the case 850M dozer while consuming less. Operators will also appreciate the redesigned, positive-pressure cab with maximum visibility and versatile controls. Who says you cant have brains and brawn? With the new case 850M, you can.

From the manufacturer:

Supplied by HeavyEquipmentData.com →

The Case 850M is a crawler dozer designed for grading, site preparation, and general earthmoving work. It is part of Case Construction Equipment's M Series and is used in construction, utility, roadbuilding, and land clearing applications. The 850M features a hydrostatic drive system, a six-way blade, and a low-ground-pressure undercarriage for traction and control on varied terrain. Operator controls are arranged for precision dozing and finish grading. The model is commonly selected for its balance of maneuverability, pushing power, and visibility in compact to mid-size dozer applications.

Blades
Blade Capacity	42 cu yd (32 cu m)
Blade Height	44 in (112 cm)
Blade Type	PAT
Blade Width	11 ft (3 m)
Capacities
Engine oil with filter	4 gal (17 l)
Dimensions
Blade depth below ground	19 in (49 cm)
Blade lift above ground	34 in (87 cm)
Ground Clearance	1 ft (0 m)
Height - Top of Cab	116 in (296 cm)
Height - Top of ROPS/FOPS	116 in (296 cm)
Length of Track on Ground	9 ft (3 m)
Width Over Tracks	8 ft (2 m)
Drive System
Final drive	2 helical gear
Max drawbar pull	47,997 lbs (21,771 kg)
Parking brakes	Heavy-duty spring-applied
Electrical System
Alternator	120 amp
Batteries	2 volts
Battery	12-volt low-maintenance
Engine
Air intake	Cross-Flow
Cooling system	Liquid
Diesel exhaust fluid (DEF) tank capacity	14 gal (52 l)
Displacement	409 cu in (6,701 cu cm)
Emission Tier Level	Tier4
Engine Model	FPT F4HFE613F
Fan	26.0 in(660mm)Diameter
Fuel	2 Diesel
Fuel injection	Common rai
Fuel tank	85 gal (322 l)
Gross Power	138 hp (103 kw)
Net Power	127 hp (95 kw)
Number of Cylinders	6
Power Measured @	2,000 rpm
Pump operating angles - Fore and aft	45 degrees
Pump operating angles -Side-to-side	35 degrees
Transmission Type	Hydrostatic
Hydraulic System
Lift cylinder - Rod diameter	2 in (5 cm)
Lift cylinder - Stroke	19 in (49 cm)
Lift cylinder(s)	2
Lift cylinder-Bore diameter	4 in (11 cm)
Pump type	Variable Displacement Piston
Operating Specifications
center rock guard	296 lbs (134 kg)
Long track	31,134 lbs (14,122 kg)
Low ground pressure	32,637 lbs (14,804 kg)
Operating Weight	32,637 lbs (14,804 kg)
Sweeps	139 lbs (63 kg)
Winch	2,447 lbs (1,110 kg)
Performance
Pump Flow	35 gpm (132 lpm)
Standard Blade
Blade Angle (both directions)	25 degrees
Transmission
Max Speed - Forward	6 mph (9 kph)
Max Speed - Reverse	6 mph (9 kph)
Undercarriage
Number of bottom rollers per side	7
Number of Shoes per Side	43
Number of Upper Rollers	2
Track Gauge	0 ft (0 m)
Width of Shoes	30 in (76 cm)
Weights
Cab	560 lbs (254 kg)
counterweight	948 lbs (430 kg)
Ripper weight	2,377 lbs (1,078 kg)
