Equipment ↠ Case ↠ Excavators ↠ 2024 Case CX350D

2024 Case CX350D For Sale in Miami, FL

Name: 2024 Case CX350D
Brand: Case
SKU: 84747359
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: Call for Price

Case Power & Equipment

Case Power & Equipment Dealer Info

Case Power & Equipment Website

Click here to email Case Power & Equipment.

Click for Phone Number

Machine Info:

Stock Number:	DAC350K7NRS7P2028
Machine Location:	MIAMI, FL
More Information:	https://casepowered.com/inventory/excavators+-+crawler/2024-case-cx350d-west+palm+beach-fl-69723b8e30e559a6b609596e/

Description:

2024 CASE, CX350D Excavators - Crawler, *** NEW MACHINE*** Call for Pricing Excavator - Standard Boom, Digging 13'3" Arm, 31.5" Steel Shoes, Free Swing, Rain Deflector, Sun Visor, Case Max View Monitor Display, Add Bucket & Attachments Also available at Orlando location (attachments may vary) Get more buckets per hour, more hours per tank and more done sooner than you ever dreamed of with the CX350D excavator. Our exclusive CIHS on the easily delivers unmatched featherability and greater fuel economy by actively managing hydraulic power throughout lift/dump and dig/curl movements. The CX350D cab is designed to provide a safe and secure working environment with outstanding visibility.

From the manufacturer:

Supplied by HeavyEquipmentData.com →

The Case CX350D is a heavy-duty excavator designed for construction, mining, and earthmoving applications. Featuring a powerful engine and advanced hydraulic system, the CX350D delivers high performance and fuel efficiency. This excavator offers a robust undercarriage, enhanced operator comfort with an ergonomic cab, and precise control for digging, lifting, and loading tasks. The Case CX350D is equipped with durable components and advanced technology to improve productivity and reduce downtime. Suitable for large-scale excavation projects, the CX350D supports various attachments, making it versatile for multiple job site requirements. It is a reliable choice in the medium to large excavator category.

Boom/Stick Excavator Option 1
Bucket rotation	173 degrees
Dig radius at ground line	4,323 in (10,981 cm)
Dump height	285 in (724 cm)
Max Digging Depth	24 ft (7 m)
Max Reach Along Ground	36 ft (11 m)
Max Vertical Wall Digging Depth	21 ft (6 m)
Minimum swing radius	178 in (451 cm)
Mximum dig radius	440 in (1,117 cm)
Boom/Stick Excavator Option 2
Bucket rotation	173 degrees
Dig radius at ground line	412 in (1,045 cm)
Dump height	280 in (711 cm)
Maximum dig radius	419 in (1,065 cm)
Maximum reach height	409 in (1,038 cm)
Minimum swing radius	178 in (451 cm)
Boom/Stick Excavator Option 3
Bucket rotation	173 degrees
Dig radius at ground line	461 in (1,171 cm)
Dump height	297 in (753 cm)
Maximum dig radius	469 in (1,190 cm)
Maximum reach height	419 in (1,065 cm)
Minimum swing radius	178 in (453 cm)
Overall height	11 ft (3 m)
Brakes
Brakes Type	Mechanical disc
Service brake	SAHR disc - each motor
Travel control	Dual stage relief or counter balance design
Capacities
Cooling system	10 gal (38 l)
DEF Tank	40 gal (152 l)
Engine oil w/ filter change	13 gal (48 l)
Final Drive	3 gal (10 l)
Hydraulic system	93 gal (350 l)
Hydraulic Tank	46 gal (175 l)
Swing drive	1 gal (5 l)
Dimensions
Boom length	0 ft (0 m)
Cab height	125 in (318 cm)
Center to center - idler to sprocket	13 ft (4 m)
Ground Clearance	2 ft (0 m)
Ground pressure	8 psi
Minimum ground clearance	19 in (47 cm)
Overall height	11 ft (3 m)
Tail Swing Radius	12 ft (4 m)
Track shoe width	3 ft (1 m)
Engine
Air filter type	Dry type element with warning restriction indicator
Bore	5 in (12 cm)
Displacement	476 cu in (7,800 cu cm)
Emission Tier Level	Tier 4
Engine Make	Isuzu
Engine Model	Isuzu 6 HK1X
Fuel Filter	Replaceable full flow spin-on cartridge
Fuel injection	Direct injection - electronic
Fuel Type	Requires ultra-low sulfur fuel B5 biodiesel tolerant
Max Torque	4 lbs ft (6 nm)
Net Power	268 hp (200 kw)
Oil Filter	Replaceable full flow spin-on cartridge
Power Measured @	1,900 rpm
Stroke	5 in (13 cm)
General Specifications
Digging Depth ft. (m) (Since 2025)	26.7 (8.1)
Digging Reach ft. (m) (Since 2025)	38.4 (11.7)
Engine hp (kW) (Since 2025)	268 (200)
Operating Weight lbs. (kg) (Since 2025)	82,483 (37,414)
Hydraulic System
Main pump - Maximum flow	128 gal (486 l)
System relief pressure	50 psi
Operating Specifications
Arm Breakout Force	40,241 lbs (18,253 kg)
Arm size	10,663 ft (3,250 m)
Operating Weight	82,484 lbs (37,414 kg)
Performance
Lift over end 10' radius	22,840 lbs (10,360 kg)
Lift over end Max. reach	9,833 lbs (4,460 kg)
Lift over side 10' radius	22,840 lbs (10,360 kg)
Lift over side Max. reach	8,488 lbs (3,850 kg)
Swing Mechanism
Swing Speed	10 rpm
Transmission
Max Speed	4 mph (6 kph)
Undercarriage
Track Shoe Width	32 in (80 cm)
Weights
counterweight	16,314 lbs (7,400 kg)
