| Air Conditioning System |
|
Air Conditioning |
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.81 kg of refrigerant which has a CO2 equivalent of 1.158 metric tonnes. |
| Cab |
|
FOPS |
ISO 3449:2005 Level I |
|
FOPS Level II |
ISO 3449:2005 Level II |
|
ROPS |
ISO 3471:2008 |
| Dimensions |
|
Bucket Pin Height - Carry Position |
7 in (18 cm)
|
|
Bucket Pin Height - Maximum Lift |
11 ft (3 m)
|
|
Bucket Pin Reach - Maximum Lift |
19 in (49 cm)
|
|
Clearance at Maximum Lift and Dump |
95 in (240 cm)
|
|
Departure Angle |
33 degrees |
|
Ground Clearance |
1 ft (0 m)
|
|
Height - Top of Cab |
7 ft (2 m)
|
|
Length - Track on Ground |
70 in (177 cm)
|
|
Length - With Bucket on Ground |
155 in (393 cm)
|
|
Length - Without Bucket |
126 in (319 cm)
|
|
Maximum Dump Angle |
54 degrees |
|
Maximum Overall Height |
159 in (403 cm)
|
|
Maximum Reach - With Arms Parallel to Ground |
52 in (132 cm)
|
|
Overall Length - Track |
89 in (227 cm)
|
|
Rack Back Angle - Maximum Height |
81 degrees |
|
Reach - Maximum Lift/Dump |
34 in (85 cm)
|
|
Roll Back Angle |
25 degrees |
|
Turning Radius from Center - Bucket (racked) |
91 in (231 cm)
|
|
Turning Radius from Center - Coupler |
58 in (148 cm)
|
|
Turning Radius from Center - Machine Rear |
74 in (188 cm)
|
|
Vehicle Width (400 mm/15.7 in tracks) |
76 in (193 cm)
|
|
Vehicle Width (450 mm/17.7 in tracks) |
78 in (198 cm)
|
| Engine |
|
Bore |
4 in (10 cm)
|
|
Displacement |
232 cu in (3,802 cu cm)
|
|
Engine Model |
Cat C3.8 DIT (turbo) |
|
Gross Power |
95 hp (71 kw)
|
|
Gross Power |
106 hp (79 kw)
|
|
Gross Power - SAE J1995 |
98 hp (73 kw)
|
|
Net Power |
95 hp (71 kw)
|
|
Net Power - ISO 9249 |
95 hp (71 kw)
|
|
Net Power - SAE 1349 |
95 hp (71 kw)
|
|
Peak Torque - 1,500 rpm - SAE J1995 |
246 ft (75 m)
|
|
Stroke |
5 in (12 cm)
|
| General Specifications |
|
category (Since 2020)
|
COMPACT TRACK LOADERS |
|
ENGINE POWER HP (KW) (Since 2016)
|
95 (71) |
|
ENGINE POWER HP (KW) (2017)
|
95 (71) |
|
ENGINE POWER HP (KW) (2019)
|
95 (71) |
|
ENGINE POWER HP (KW) (2020)
|
95 (71) |
|
MODEL (Since 2016)
|
299D2 |
|
MODEL (2017)
|
299D2 |
|
MODEL (2019)
|
299D2 |
|
MODEL (2020)
|
299D2 |
|
OPERATING LOAD LBS. (KG) (Since 2016)
|
4,600 (2,087) |
|
OPERATING LOAD LBS. (KG) (2017)
|
4,600 (2,087) |
|
OPERATING WIDTH IN. (CM) (Since 2016)
|
76 (193) / 78 (198) |
|
OPERATING WIDTH IN. (CM) (2017)
|
76 (193) / 78 (198) |
|
OPERATING WIDTH IN. (CM) (2019)
|
76 (193) / 78 (198) |
|
OPERATING WIDTH IN. (CM) (2020)
|
76 (193) / 78 (198) |
|
RATED OPERATING CAPACITY LBS. (KG) (35%) (Since 2020)
|
3,200 (1,452) |
|
RATED OPERATING CAPACITY LBS. (KG) (50%) (Since 2019)
|
3,200 (1,452) |
| Hydraulic System |
|
Hydraulic Flow - High Flow XPS - Hydraulic Power (Calculated) |
76 hp (57 kw)
|
|
Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Flow |
32 gpm (121 lpm)
|
|
Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Pressure |
4,061 psi |
|
Hydraulic Flow - Standard - Hydraulic Power (Calculated) |
44 hp (33 kw)
|
|
Hydraulic Flow - Standard - Loader Hydraulic Flow |
23 gpm (87 lpm)
|
|
Hydraulic Flow - Standard - Loader Hydraulic Pressure |
3,335 psi |
| Loader |
|
Operating Load Rating |
4,600 lbs (2,087 kg)
|
|
Operating Load Rating |
4,725 lbs (2,143 kg)
|
|
Operating Width |
76 in (193 cm)
|
|
Operating Width |
76 in (193 cm)
|
| Noise Level |
|
Inside Cab* |
83 dB(A) |
|
Note (1) |
Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe. |
|
Note (3) |
**The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC. |
|
Outside Cab** |
104 dB(A) |
| Operating Specifications |
|
Breakout Force - Lift Cylinder |
6,162 lbs (2,795 kg)
|
|
Breakout Force - Tilt Cylinder |
7,270 lbs (3,298 kg)
|
|
Ground Contact Area - With 400 mm/15.7 in Track |
2,184 cu in (35,789 cu cm)
|
|
Ground Contact Area - With 450 mm/17.7 in Track |
2,463 cu in (40,361 cu cm)
|
|
Ground Pressure - With 400 mm/15.7 in Track |
5 psi |
|
Ground Pressure - With 450 mm/17.7 in Track |
5 psi |
|
Rated Operating Capacities - 35% Tipping Load |
3,200 lbs (1,452 kg)
|
|
Rated Operating Capacities - 50% Tipping Load |
4,600 lbs (2,087 kg)
|
|
Rated Operating Capacity with Optional Counterweight |
4,860 lbs (2,204 kg)
|
|
Tipping Load |
9,200 lbs (4,173 kg)
|
| Power Train |
|
Travel Speed - Forward or Reverse - One Speed |
5 mph (8 kph)
|
|
Travel Speed - Forward or Reverse - Two Speed |
8 mph (14 kph)
|
| Service Refill Capacities |
|
Cooling System |
4 gal (16 l)
|
|
Diesel Exhaust Fluid (DEF) Tank |
5 gal (19 l)
|
|
Engine Crankcase |
4 gal (13 l)
|
|
Fuel Tank |
32 gal (122 l)
|
|
Hydraulic System |
15 gal (55 l)
|
|
Hydraulic Tank |
10 gal (39 l)
|
