Equipment ↠ Caterpillar ↠ Crawler Loaders ↠ 1983 Caterpillar 931B

1983 Caterpillar 931B For Sale in MT VERNON, IL

Name: 1983 Caterpillar 931B
Brand: Caterpillar
SKU: 82094234
Price: 28000 USD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $28,000.00 USD

Apply for Financing

McCoy Construction & Forestry

McCoy Construction & Forestry Dealer Info

McCoy Construction & Forestry Website

Click here to email McCoy Construction & Forestry.

Contact: Anthony Abert

Click for Phone Number

Machine Info:

Serial Number:	29Y01319
Stock Number:	304158
Machine Location:	MT VERNON, IL

Description:

ROPS, RIPPER, PEDAL STEER, GP BUCKET

Machine Details:

General Specifications
Operators Station	Pedal Steer
Tracks	Standard Track
Buckets	General Purpose Bkt
Attachments	Ripper

From the manufacturer:

Supplied by HeavyEquipmentData.com →

Dimensions
Clearance at Full Height and Dump	8 ft (2 m)
Ground Clearance	1 ft (0 m)
Height - Top of Cab	9 ft (3 m)
Length to Front of Track	9 ft (3 m)
Length with Bucket on Ground	13 ft (4 m)
Reach at Dump Height	3 ft (1 m)
Width to Outside of Tracks	6 ft (2 m)
Engine
Displacement	317 cu in (5,201 cu cm)
Engine Model	3,204
Net Power	64 hp (48 kw)
Number of Cylinders	4
Power Measured @	2,400 rpm
Hydraulic System
Dump Time	1 seconds
Lower Time	4 seconds
Pump Flow Capacity	23 gpm (87 lpm)
Pump Type	Single-section gear pump
Raise Time	6 seconds
Relief Valve Pressure	2,500 psi
Operating Specifications
Alternator Supplied Amperage	40 amps
Breakout Force Bucket	11,560 lbs (5,244 kg)
Bucket Capacity - heaped	1 cu yd (1 cu m)
Bucket Capacity - struck	1 cu yd (1 cu m)
Cooling System Fluid Capacity	5 gal (20 l)
Engine Oil Capacity	3 gal (12 l)
Final Drive Fluid Capacity - each	2 gal (8 l)
Fuel Capacity	31 gal (116 l)
Hydraulic System Fluid Capacity	20 gal (76 l)
Max Speed	7 mph (11 kph)
Operating Voltage	12 volts
Operating Weight	15,331 lbs (6,954 kg)
Static Tipping Load	9,083 lbs (4,120 kg)
Undercarriage
Ground Contact Area	1,721 cu in (28,196 cu cm)
Ground Pressure	9 psi
Length of Track on Ground	6 ft (2 m)
Number of Shoes per Side	36
Number of Track Rollers per Side	5
Track Gauge	56 in (142 cm)
Track Shoe Width	12 in (31 cm)
