Equipment ↠ Caterpillar ↠ Excavators ↠ 1998 Caterpillar 315BL

1998 Caterpillar 315BL For Sale in Lansing, MI

Name: 1998 Caterpillar 315BL
Brand: Caterpillar
SKU: 87737389
Price: 34900 USD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $34,900.00 USD

Apply for Financing

AIS Construction Equipment

AIS Construction Equipment Dealer Info

AIS Construction Equipment Website

Click here to email AIS Construction Equipment.

Click for Phone Number

Machine Info:

Hours:	8192
Serial Number:	AW01016
Stock Number:	H68091
Machine Location:	LANSING, MI

Description:

CATERPILLAR 315BL

From the manufacturer:

Supplied by HeavyEquipmentData.com →

Boom/Stick Excavator Option 1
Max Cutting Height	28 ft (9 m)
Max Digging Depth	18 ft (5 m)
Max Loading Height	20 ft (6 m)
Max Reach Along Ground	26 ft (8 m)
Max Vertical Wall Digging Depth	15 ft (4 m)
Boom/Stick Excavator Option 2
Max Cutting Height	29 ft (9 m)
Max Digging Depth	19 ft (6 m)
Max Loading Height	20 ft (6 m)
Max Reach Along Ground	28 ft (8 m)
Max Vertical Wall Digging Depth	16 ft (5 m)
Shipping Height of Unit	9 ft (3 m)
Shipping Length of Unit	28 ft (8 m)
Boom/Stick Excavator Option 3
Max Cutting Height	29 ft (9 m)
Max Digging Depth	20 ft (6 m)
Max Loading Height	21 ft (6 m)
Max Reach Along Ground	29 ft (9 m)
Max Vertical Wall Digging Depth	18 ft (5 m)
Shipping Length of Unit	28 ft (9 m)
Boom/Stick Excavator Option 4
Max Cutting Height	30 ft (9 m)
Max Digging Depth	22 ft (7 m)
Max Loading Height	21 ft (6 m)
Max Reach Along Ground	30 ft (9 m)
Max Vertical Wall Dig Depth	18 ft (6 m)
Shipping Length of Unit	28 ft (9 m)
Bucket
Maximum Bucket Capacity	1 cu yd (1 cu m)
Minimum Bucket Capacity	1 cu yd (0 cu m)
Reference Bucket Capacity	1 cu yd (1 cu m)
Dimensions
Ground Clearance	2 ft (0 m)
Height - Top of Cab	10 ft (3 m)
Length of Track on Ground	11 ft (3 m)
Removal Counterweight Clearance	4 ft (1 m)
Tail Swing Radius	8 ft (2 m)
Width to Outside of Tracks	9 ft (3 m)
DRIVE SYSTEM
Maximum Drawbar Pull	29,480 lbs (13,372 kg)
Travel Speed	3 mph (5 kph)
Engine
Aspiration	Turbocharged
Bore	4 in (9 cm)
Displacement	305 cu in (4,998 cu cm)
Engine Model	Cat 3046T Diesel Engine
Flywheel Power	99 hp (74 kw)
Gross Power	102 hp (76 kw)
ISO 9249	99 hp (74 kw)
Net Power	99 hp (74 kw)
Power Measured @	2,100 rpm
SAE J1349	99 hp (74 kw)
Stroke	5 in (12 cm)
Hydraulic System
Boom Cylinder - Bore	4 in (11 cm)
Boom Cylinder - Stroke	47 in (119 cm)
Main Implement System - Maximum Flow (2x)	70 gpm (265 lpm)
Maximum Pressure - Implements	4,980 psi
Maximum Pressure - Swing	3,340 psi
Maximum Pressure - Travel	4,980 psi
Stick Cylinder - Bore	5 in (12 cm)
Stick Cylinder - Stroke	52 in (133 cm)
Operating Specifications
Alternator Supplied Amperage	50 amps
Cooling System Fluid Capacity	5 gal (19 l)
Engine Oil Capacity	4 gal (13 l)
Fuel Capacity	74 gal (280 l)
Hydraulic Pump Flow Capacity	70 gpm (264 lpm)
Hydraulic System Fluid Capacity	50 gal (188 l)
Hydraulic System Relief Valve Pressure	4,980 psi
Operating Voltage	24 volts
Operating Weight	36,200 lbs (16,420 kg)
Swing Drive Fluid Capacity	1 gal (3 l)
Service Refill Capacities
Cooling System	5 gal (19 l)
Engine Oil	3 gal (13 l)
Final Drive - Each	1 gal (3 l)
Fuel Tank	74 gal (280 l)
Hydraulic System - Including Tank	49 gal (185 l)
Hydraulic Tank	27 gal (103 l)
Swing Drive - Each	1 gal (3 l)
Swing Mechanism
Swing Speed	10 rpm
Undercarriage
Drawbar Pull	29,480 lbs (13,372 kg)
Ground Pressure	6 psi
Max Travel Speed	4 mph (6 kph)
Shoe Size	24 in (60 cm)
Track Gauge	7 ft (2 m)
Weights
Operating Weight	37,000 lbs (16,783 kg)
