| Axles |
|
Front |
Fixed |
|
Rear |
Trunnion |
| Brakes |
|
Brakes |
SAE J1473 OCT90 ISO 3450:1992 |
| Engine |
|
Bore |
6 in (14 cm)
|
|
Displacement |
1,105 cu in (18,108 cu cm)
|
|
Engine Model |
Cat C18 ACERT |
|
Gross - ISO 14396 |
580 hp (433 kw)
|
|
Make |
Cat |
|
Net Power |
541 hp (403 kw)
|
|
Net Power - SAE J1349 |
541 hp (403 kw)
|
|
Peak Power Speed - 1,500 rpm - Gross - ISO 14396 |
580 hp (433 kw)
|
|
Peak Power Speed - 1,500 rpm - Gross - SAE J1995 |
588 hp (438 kw)
|
|
Peak Power Speed - 1,500 rpm - Net Power - SAE J1349 |
541 hp (403 kw)
|
|
Peak Torque - 1,200 rpm |
2,104 lbs ft (2,853 nm)
|
|
Rated Speed |
1,700 rpm |
|
Stroke |
7 in (18 cm)
|
|
Torque Rise |
58% |
| General Specifications |
|
Breakout Force (Since 2021)
|
87,122 lbs ft (118,120 nm)
|
|
Breakout Force (Since 2023)
|
98,421 lbs ft (133,439 nm)
|
|
Bucket Capacity (Since 2017)
|
8.3 - 10.0 (6.3 - 7.6) |
|
Bucket Capacity (2019)
|
8.3 - 10.0 (6.3 - 7.6) |
|
Bucket Capacity (2020)
|
8.3 - 10.0 (6.3 - 7.6) |
|
Bucket Capacity (Since 2021)
|
8.1.10 cu yd |
|
Bucket Capacity (Since 2021)
|
6.5 - 13.5 (5.0 - 10.3) |
|
Bucket Capacity (2022)
|
6.5 - 13.5 (5.0 - 10.3) |
|
Bucket Capacity (Since 2023)
|
6.2.17 cu yd |
|
Bucket Capacity (Since 2023)
|
6.5 - 13.5 (5.0 - 10.3) |
|
Bucket Capacity (2024)
|
6.5 - 13.5 (5.0 - 10.3) |
|
Bucket Capacity cu. yd. (cu m) (Since 2016)
|
8.3 - 10.0 (6.3 - 7.6) |
|
Engine (Since 2021)
|
C18 ACERT |
|
Engine (Since 2023)
|
C18 |
|
Engine Power (Since 2017)
|
541 (403) |
|
Engine Power (2019)
|
541 (403) |
|
Engine Power (2020)
|
541 (403) |
|
Engine Power (2021)
|
541 (403) |
|
Engine Power (2022)
|
541 (403) |
|
Engine Power (2023)
|
541 (403) |
|
Engine Power (2024)
|
541 (403) |
|
Engine Power hp (kw) (Since 2016)
|
541 (403) |
|
Engine type (Since 2016)
|
Cat C18 ACERT |
|
Engine type (2017)
|
Cat C18 ACERT |
|
Engine type (2019)
|
Cat C18 ACERT |
|
Engine type (Since 2020)
|
Cat C18 |
|
Engine type (2021)
|
Cat C18 |
|
Engine type (2022)
|
Cat C18 |
|
Engine type (2023)
|
Cat C18 |
|
Engine type (2024)
|
Cat C18 |
|
Full-Turn Tip Load (Since 2021)
|
79,435 lbs (36,031 kg)
|
|
Full-Turn Tipping Load (Since 2023)
|
79,435 lbs (36,031 kg)
|
|
Max Dump Height (Since 2017)
|
6.8 (2.1) |
|
Max Dump Height (Since 2019)
|
11.3 (3.4) |
|
Max Dump Height (2020)
|
11.3 (3.4) |
|
Max Dump Height ft.( m) (Since 2016)
|
6.8 (2.1) |
|
Net Power (Since 2021)
|
541 hp (403 kw)
|
|
Net Power (Since 2023)
|
538 hp (401 kw)
|
|
Operating Weight (Since 2017)
|
112,574 (51,063) |
|
Operating Weight (2019)
|
112,574 (51,063) |
|
Operating Weight (2020)
|
112,574 (51,063) |
|
Operating Weight (Since 2021)
|
112,574 lbs (51,063 kg)
|
|
Operating Weight (Since 2021)
|
112,574 (51,063) |
|
Operating Weight (2022)
|
112,574 (51,063) |
|
Operating Weight (Since 2023)
|
112,574 lbs (51,063 kg)
|
|
Operating Weight (Since 2023)
|
112,574 (51,063) |
|
Operating Weight (2024)
|
112,574 (51,063) |
|
Operating Weight lbs. (kg) (Since 2016)
|
112,574 (51,063) |
|
Tip Load (Since 2021)
|
63,404 (28,760) |
|
Tip Load (2022)
|
63,404 (28,760) |
|
Tip Load (2023)
|
63,404 (28,760) |
|
Tip Load (2024)
|
63,404 (28,760) |
|
Travel Speed (Since 2024)
|
24 / 25.4 mph |
|
Travel Speed(Fwd/Rev) (Since 2021)
|
24 / 25.4 mph |
|
Travel Speed(Fwd/Rev) (2022)
|
24 / 25.4 mph |
|
Travel Speed(Fwd/Rev) (2023)
|
24 / 25.4 mph |
| Hydraulic Cycle Times |
|
Dump |
2 seconds |
|
Lower Float Down |
4 seconds |
|
Rack Back |
5 seconds |
|
Raise |
8 seconds |
|
Total Hydraulic Cycle Time - Empty Bucket |
18 seconds |
| Hydraulic System - Lift/Tilt |
|
Lift/Tilt System |
Variable displacement piston |
|
Maximum Flow at 1,400-1,860 rpm |
153 gpm (579 lpm)
|
|
Pilot System |
Variable displacement piston |
| Hydraulic System - Steering |
|
Steering Cycle Times - High Idle |
3 seconds |
|
Steering Cycle Times - Low Idle |
6 seconds |
|
Steering System - Circuit |
Pilot load sensing |
|
Steering System - Pump |
Piston variable displacement |
| Operating Specifications |
|
Cat Truck Match - High Lift |
773-775 |
|
Cat Truck Match - Standard |
770-772 |
|
Rated Bucket Capacity |
8 - 10 cu yd (6 - 8 cu m)
|
|
Rated Payload |
27,558 lbs (12,500 kg)
|
|
Rated Payload - High Lift |
27,558 lbs (12,500 kg)
|
|
Rated Payload - Standard |
27,558 lbs (12,500 kg)
|
|
Tipping Load - Articulated 37 degrees |
68,005 lbs (30,847 kg)
|
|
Tipping Load - Straight |
78,115 lbs (35,432 kg)
|
| Service Refill Capacities |
|
Cooling System |
32 gal (120 l)
|
|
Crankcase |
16 gal (60 l)
|
|
Diesel Exhaust Fluid Tank |
9 gal (33 l)
|
|
Differential - Final Drives - Front |
49 gal (186 l)
|
|
Differential - Final Drives - Rear |
49 gal (186 l)
|
|
Hydraulic System - Tank Only |
63 gal (240 l)
|
|
Hydraulic System Factory Fill |
126 gal (475 l)
|
|
Transmission |
32 gal (120 l)
|
| Sound Performance - Standard |
|
Machine Sound Level (ISO 6395) |
111 dB(A) |
|
Operator Sound Level (ISO 6396) |
71 dB(A) |
| Sound Performance - Suppression |
|
Machine Sound Level (ISO 6395) |
109 dB(A) |
|
Operator Sound Level (ISO 6396) |
70 dB(A) |
| Transmission |
|
Direct Drive - Forward 1 |
Lock-up disabled |
|
Transmission Type |
Cat planetary power shift |
