For Sale: Call for Price
| Machine Location: | EAST WINDSOR, NEW JERSEY |
Supplied by HeavyEquipmentData.com →
| Bucket | |
| Dump Clearance at Max Raise | 18' 10" |
| Dimensions | |
| Angle of Articulation | 35 degrees |
| Bucket Articulation | 45 degrees |
| Clearance Distance | 18' 10" |
| Max Dumping Height | 8' 6" |
| Minimum Ground Clearance | 1' 2" |
| Overall Height | 9' 10" |
| Overall Height Bucket Raised | 13' 3" |
| Overall Length with Bucket | 18' 9" |
| Overall Length Without Bucket | 17' 4" |
| Overall Width | 6' 6" |
| Reach With Bucket Raised | 4' 3" |
| Wheel Base | 7' 5" |
| Driving | |
| Brakes | Hydraulic Caliper Disc Brakes |
| Forward I Speed | 6 mph (10 kph) |
| Forward II Speed | 16 mph (26 kph) |
| Hub Reductor Type | Spur Gear Planet Drive |
| Main Drive | Spiral Bevel Gear One Stage Reduction |
| Motor Type | Permanent Magnet Synchronization |
| Rated Power | 57 kw (76 hp) |
| Rated Voltage | 380 volts |
| Reverse Speed | 6 mph (10 kph) |
| Steering Mode | Articulated Frame Steering |
| Tire | 16/70-20PR |
| Transmission Gear | 2 Forward 1 Reverse |
| Transmission Type | Hydraulic |
| Driving Hydraulics | |
| Drive/Steering Oil Capacity | 4 gal (15 l) |
| Proctection grade IP67 | Yes |
| Steering Output Volume | 15 ml/r |
| Steering Service Pressure | 2,175 psi |
| Transmission Oil Capacity | 4 gal (15 l) |
| General Specifications | |
| Bucket Capacity | 1 cu yd (1 cu m) |
| Bucket Capacity (Since 2023) | 1.3 (1.0) |
| Descent Time | 3 seconds |
| Dumping Distance | 3' 2" |
| Engine Power (Since 2023) | 78 (57) |
| Engine type (Since 2023) | Electric (141 kWh) |
| Lifting Time | 6 seconds |
| Max Dump Height (Since 2023) | 8.5 (2.6) |
| Maximum Digging Force | 50 newton |
| Maximum Gradeability | 35% |
| Operating Weight | 11,464 lbs (5,200 kg) |
| Operating Weight (Since 2023) | 11,464 (5,200) |
| Rated Load | 3,968 lbs (1,800 kg) |
| Rear Axle Lateral Swing Angle | 7 degrees |
| Tipping Load | 8,378 lbs (3,800 kg) |
| Unloading Time | 2 seconds |
| Wheel Tread | 4' 11" |
| Operating Specifications | |
| Operating Weight | 11,464 lbs (5,200 kg) |
