For Sale: Call for Price
| Machine Location: | EAST WINDSOR, NEW JERSEY |
Supplied by HeavyEquipmentData.com →
| Dimensions | |
| Angle of Articulation | 35 degrees |
| Bucket Articulation | 45 degrees |
| Clearance Distance | 28' 8" |
| Max Dumping Height | 10' 2" |
| Minimum Ground Clearance | 1' 5" |
| Overall Height | 11' 1" |
| Overall Height Bucket Raised | 14' 6" |
| Overall Length with Bucket | 28' 6" |
| Overall Length Without Bucket | 26' 2" |
| Overall Width | 9' 11" |
| Reach With Bucket Raised | 4' 3" |
| Wheel Base | 10' 10" |
| General Specifications | |
| Bucket Capacity | 4 cu yd (3 cu m) |
| Bucket Capacity (Since 2023) | 3.9 (3.0) |
| Descent Time | 5 seconds |
| Dumping Distance | 3' 7" |
| Engine Power (Since 2023) | 164 (120) |
| Engine type (Since 2023) | Electric (242 kWh) |
| Lifting Time | 6 seconds |
| Max Dump Height (Since 2023) | 10.17 (3.1) |
| Maximum Digging Force | 160 newton |
| Maximum Gradeability | 53% |
| Operating Weight | 39,683 lbs (18,000 kg) |
| Operating Weight (Since 2023) | 39,683 (18,000) |
| Rated Load | 12,125 lbs (5,500 kg) |
| Rear Axle Lateral Swing Angle | 7 degrees |
| Tipping Load | 17,637 lbs (8,000 kg) |
| Unloading Time | 2 seconds |
| Wheel Tread | 7' 6" |
| Operating Specifications | |
| Operating Weight | 39,683 lbs (18,000 kg) |
