2018 Hitachi ZX85USB-5 For Sale in Saskatoon, SK

Name: 2018 Hitachi ZX85USB-5
Brand: Hitachi
SKU: 87653995
Price: 155000 CAD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $113,738.00 USD
Converted From: 155,000.00 CAD

Apply for Financing

Korpan Tractor

Korpan Tractor Dealer Info

Korpan Tractor Website

Click here to email Korpan Tractor.

Contact: Main

Click for Phone Number

Machine Info:

Stock Number:	K2449
Machine Location:	SASKATOON, SK

From the manufacturer:

Supplied by HeavyEquipmentData.com →

The Hitachi ZX85USB-5 is a compact excavator designed for versatile construction and excavation tasks. Featuring a reduced tail swing radius, the ZX85USB-5 excels in confined spaces while maintaining powerful digging performance. Equipped with a fuel-efficient engine, advanced hydraulic system, and robust undercarriage, this model delivers enhanced productivity and durability. Its operator cabin offers improved visibility, ergonomic controls, and noise reduction for increased comfort. The ZX85USB-5 supports various attachments, making it suitable for trenching, landscaping, and utility work. This excavator is widely used in urban construction, infrastructure projects, and site development, combining maneuverability with reliable heavy-duty operation.

Boom/Stick Excavator Option 1
Arm Digging Force - SAE	6,902 lbs (3,131 kg)
Bucket Digging Force - SAE	10,476 lbs (4,752 kg)
Max Cutting Height	24 ft (7 m)
Max Digging Depth	15 ft (5 m)
Max Digging Reach	3 ft (1 m)
Max Reach Along Ground	25 ft (8 m)
Max Vertical Wall Digging Depth	13 ft (4 m)
Capacities
Engine oil with filter	3 gal (12 l)
Fuel Tank	36 gal (135 l)
Hydraulic system	27 gal (103 l)
Hydraulic Tank	15 gal (56 l)
Propel	0 gal (2 l)
Cylinders
Bore (Arm)	4 in (10 cm)
Bore (Boom)	5 in (12 cm)
Bore (Bucket)	3 in (9 cm)
Rod Diameter (Arm)	2 in (6 cm)
Rod Diameter (Boom)	3 in (7 cm)
Rod Diameter (Bucket)	2 in (6 cm)
Stroke (Arm)	36 in (90 cm)
Stroke (Boom)	35 in (89 cm)
Stroke (Bucket)	29 in (73 cm)
Dimensions
Cab Height	9 ft (3 m)
Counterweight Clearance	2 ft (1 m)
Ground Clearance	1 ft (0 m)
Length	2,685 in (6,820 cm)
Tail Swing Radius	5 ft (1 m)
Undercarriage Overall Length	10 ft (3 m)
Electrical System
Alternator rating	50 amp
Batteries	2 x 12 V volts
Battery capacity	450CCA
Work Lights	2 halogen
Engine
Aspiration	Natural
Cooling system	High efficiency direct-driven suction-type fan
Displacement	201 cu in (3,300 cu cm)
Emissions level	EPA Final Tier 4 / EU Stage IV
Engine Make	Yanmar
Engine Model	4TNV98C-WHBW
Net Power	57 hp (42 kw)
Off-Level Capacity	70%
Power Measured @	2,000 rpm
Hydraulic System
Controls	Pilot levers
Implement - Operating Pressure	3,771 psi
Main pump type	3 variable-displacement axial-piston pumps
Travel - Operating Pressure	4,554 psi
Operating Specifications
Cooling System Fluid Capacity	3 gal (10 l)
Hydraulic Pump Flow Capacity	53 gpm (200 lpm)
Hydraulic System Relief Valve Pressure	566 psi
Operating Weight	17,952 lbs (8,143 kg)
Swing Mechanism
Swing Speed	11 rpm
Undercarriage
Drawbar Pull	14,661 lbs (6,650 kg)
Max Travel Speed	3 mph (5 kph)
Number of Shoes per Side	40
