2017 JCB 260 For Sale in Harrisburg, PA

Name: 2017 JCB 260
Brand: JCB
SKU: 86725448
Price: 39900 USD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $39,900.00 USD

Apply for Financing

Stephenson Equipment, Inc.

Stephenson Equipment, Inc. Dealer Info

Stephenson Equipment, Inc. Website

Click here to email Stephenson Equipment, Inc..

Contact: Kyle Hoffman

Click for Phone Number

Machine Info:

Hours:	937
Stock Number:	GE0260WVVH2503074
Machine Location:	HARRISBURG, PA
More Information:	https://stephensonequipmentjcb.com/inventory/skid+steers+-+wheel/2017-jcb-260-prospect-pa-69d11a209a2ecda8900d0a9c/

Description:

2017 JCB, 260 Skid Steers - Wheel, 2017 JCB 260 Skid Steer, 937 Hours, Cab, Heat & Air, 2-Speed, Hi-Flow, Hydraulic Skid Steer Q/A, 78" GP Bucket, 12.5x16.5 Tires. *Stephenson Equipment has a large inventory spread out across 8 locations in PA & NY. Please contact us before coming to inspect a piece of equipment.

From the manufacturer:

Supplied by HeavyEquipmentData.com →

Dimensions
Clearance at Max Lift and Dump	8 ft (2 m)
Ground Clearance	9 in (24 cm)
Height - Top of Cab	7 ft (2 m)
Length with Bucket	12 ft (4 m)
Reach at Max Lift and Dump	34 in (87 cm)
Turning Radius from Center - inc bucket	87 in (220 cm)
Turning Radius from Center - machine rear	69 in (176 cm)
Wheelbase	4 ft (1 m)
Width Over Tires	6 ft (2 m)
Engine
Aspiration	Turbocharged
Displacement	268 cu in (4,392 cu cm)
Engine Model	TC-63
Gross Power	84 hp (63 kw)
Max Torque	267 lbs ft (362 nm)
Power Measured @	2,400 rpm
Torque Measured @	1,800 rpm
General Specifications
ENGINE POWER HP (KW) (Since 2016)	74 (55)
MODEL (Since 2016)	260
OPERATING LOAD LBS. (KG) (Since 2016)	2,600 (1,179)
OPERATING WIDTH IN. (CM) (Since 2016)	72 (183)
Hydraulic System
Pump Flow Capacity	23 gpm (87 lpm)
Relief Valve Pressure	3,335 psi
Loader
Bucket Capacity	1 cu yd (1 cu m)
Operating Load Rating	2,600 lbs (1,179 kg)
Operating Width	72 in (183 cm)
Tipping Angle	5,448 degrees
Operating Specifications
Alternator Supplied Amperage	95 amps
Chain Box Fluid Capacity - each side	6 gal (23 l)
Cooling System Fluid Capacity	4 gal (16 l)
Engine Oil Fluid Capacity	4 gal (14 l)
Fuel Capacity	27 gal (103 l)
Hydraulic System Fluid Capacity	16 gal (60 l)
Max Speed	12 mph (20 kph)
Operating Speed	7 mph (11 kph)
Operating Voltage	12 volts
Operational Weight	7,971 lbs (3,616 kg)
Tire Size	12 x 16.5
