2023 JCB 270 For Sale in Auburn, KY

Name: 2023 JCB 270
Brand: JCB
SKU: 83714281
Price: 53000 USD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $53,000.00 USD

Apply for Financing

Shaker JCB

Shaker JCB Dealer Info

Click here to email Shaker JCB.

Click for Phone Number

Machine Info:

Hours:	520
Machine Location:	AUBURN, KY
More Information:	https://shakerjcb.com/inventory/skid+steers/2023-jcb-270-auburn-ky-693b1c9ac3c461258408e049/

Description:

Fully-welded chassis provides a rigid structure for maximum strength and reduced weight. A solid undercarriage with cast steel, triple-flanged rollers provides consistent performance on demanding terrain.

From the manufacturer:

Supplied by HeavyEquipmentData.com →

The JCB 270 is a skid steer loader designed for material handling, site preparation, and general construction work. It is part of JCB's skid steer range and is commonly used in landscaping, agriculture, utilities, and building applications. The machine features a compact frame, high breakout force, and a vertical lift path for loading trucks and placing materials at height. Depending on configuration, the JCB 270 may be equipped with auxiliary hydraulics, a quick-attach system, and a range of compatible attachments. Its design supports maneuverability in confined spaces while maintaining lifting performance for demanding jobsite tasks.

Capacities
Engine coolant	6 gal (22 l)
Engine Oil	4 gal (15 l)
Fuel Tank	27 gal (103 l)
Hydraulic system	15 gal (55 l)
Dimensions
Angle of departure	29 degrees
Bucket corner Turning radius	8 ft (2 m)
Dig Depth	394 in (1,000 cm)
Dump angle	42 degrees
Dump Height	8 ft (2 m)
Ground Clearance	10 in (25 cm)
Loadover height	9,515 ft (2,900 m)
Max. reach @ full height	4 ft (1 m)
Overall height	7 ft (2 m)
Overall Length	153 in (388 cm)
Pin height	11 ft (3 m)
Quick hitch Turning radius	5 ft (2 m)
Reach @ ground level	4 ft (1 m)
Rear chassis turning radius	6 ft (2 m)
Rollback - Ground Level	30 degrees
Wheelbase	4 ft (1 m)
Width over tires	71 in (180 cm)
Engine
Alternator	95 amps
Aspiration	Turbo
Battery	12 V
Cooling system	Diesel
Displacement	4,399 cu in (72,087 cu cm)
Emissions Certification	EPA-T4F (EU St3B)
Engine Model	EcoMAX TCAE-55
Engine oil service interval	500 hours
Fuel	Diesel
Gross Power	74 hp (55 kw)
Hydraulically driven cooling fan	Yes
Max Torque	295 lbs ft (400 nm)
Power Measured @	2,400 rpm
Torque Measured @	1,200 rpm
General Specifications
ENGINE POWER HP (KW) (Since 2017)	74 (55)
ENGINE POWER HP (KW) (2019)	74 (55)
ENGINE POWER HP (KW) (2020)	74 (55)
Engine Power HP (KW) (Since 2021)	74 (55)
Engine Power HP (KW) (2022)	74 (55)
Engine Power HP (KW) (2023)	74 (55)
Engine Power HP (KW) (2024)	74 (55)
Engine Power HP (KW) (2025)	74 (55)
MODEL (Since 2017)	270
MODEL (2019)	270
MODEL (2020)	270
OPERATING LOAD LBS. (KG) (Since 2017)	2,600 (1,179)
OPERATING WIDTH IN. (CM) (Since 2017)	72 (183)
OPERATING WIDTH IN. (CM) (Since 2019)	75 (190)
OPERATING WIDTH IN. (CM) (2020)	75 (190)
Operating Width IN. (CM) (Since 2021)	75 (190)
Operating Width IN. (CM) (2022)	75 (190)
Operating Width IN. (CM) (2023)	75 (190)
Operating Width IN. (CM) (2024)	75 (190)
Operating Width IN. (CM) (2025)	75 (190)
Rated Operating Capacity LBS. (KG) (Since 2025)	2,723 (1,235)
RATED OPERATING CAPACITY LBS. (KG) (50%) (Since 2019)	2,723 (1,235)
RATED OPERATING CAPACITY LBS. (KG) (50%) (2020)	2,723 (1,235)
Rated Operating Capacity LBS. (KG) 50% (Since 2021)	2,723 (1,235)
Rated Operating Capacity LBS. (KG) 50% (2022)	2,723 (1,235)
Rated Operating Capacity LBS. (KG) 50% (2023)	2,723 (1,235)
Rated Operating Capacity LBS. (KG) 50% (2024)	2,723 (1,235)
Hydraulic System
Pump Flow Capacity	24 gpm (90 lpm)
Relief Valve Pressure	484 psi
Loader
Breakout Force	6,543 lbs (2,968 kg)
Bucket Capacity	1 cu yd (0 cu m)
Bucket Width	78 in (199 cm)
Loader lift capacity with bucket	6,056 lbs (2,747 kg)
Operating Load Rating	2,600 lbs (1,179 kg)
Operating Width	72 in (183 cm)
Tipping Angle	5,448 degrees
Operating Specifications
Operational Weight	8,680 lbs (3,937 kg)
Tires
Standard	12 x 16.5 - 10 PR Xtra Wall Off Road
Transmission
Travel Speed	12 mph (19 kph)
