2025 JCB 300 For Sale in Phoenix, AZ

Name: 2025 JCB 300
Brand: JCB
SKU: 86823306
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: Call for Price

Southwest JCB

Southwest JCB Dealer Info

Southwest JCB Website

Click here to email Southwest JCB .

Click for Phone Number

Machine Info:

Hours:	10
Stock Number:	3418202
Machine Location:	PHOENIX, AZ
More Information:	https://swjcb.com/inventory/skid+steers/2025-jcb-300-las+cruces-nm-69d814dcfbf6f3f4b50bc052/

Description:

Skid Steer Loader The large platform, Hi-Viz, JCB 300 skid steer loader provides the operator with excellent visibility to the attachment. The JCB 300 is a vertical lift machine with a rated operating capacity of 3,186 lbs., making it ideal for applications that require heavy, high-flow attachments for clearing material, mulching, and agricultural tasks.

From the manufacturer:

Supplied by HeavyEquipmentData.com →

The JCB 300 skid steer loader is a versatile compact construction machine designed for material handling, excavation, and site preparation. Equipped with a powerful engine and robust hydraulic system, the JCB 300 delivers high performance and efficiency in tight spaces. Its durable frame and advanced loader arms provide excellent lifting capacity and reach. The operator cabin offers ergonomic controls and enhanced visibility for improved safety and productivity. Suitable for landscaping, agriculture, and construction applications, the JCB 300 skid steer loader supports various attachments, including buckets, forks, and augers, making it a flexible solution for diverse job site requirements.

Dimensions
Angle of departure	29 degrees
Clearance at Max Lift and Dump	8 ft (2 m)
Dig Depth	394 in (1,000 cm)
Dump angle	42 degrees
Dump Height	8 ft (2 m)
Ground Clearance	10 in (25 cm)
Height - Top of Cab	7 ft (2 m)
Length with Bucket	13 ft (4 m)
Loadover height	9,515 ft (2,900 m)
Pin height	10,499 ft (3,200 m)
Reach at Max Lift and Dump	36 in (90 cm)
Rollback - Ground Level	30 degrees
Turning Radius from Center - inc bucket	87 in (220 cm)
Turning Radius from Center - machine rear	69 in (176 cm)
Wheelbase	4 ft (1 m)
Width Over Tires	6 ft (2 m)
Engine
Aspiration	Turbo
Battery	12 V
Cooling system	Liquid
Displacement	268 cu in (4,392 cu cm)
Emissions Certification	EPA-T4F (EU St3B)
Engine Model	EcoMAX TCAE-55
Engine oil service interval	500 hours
Fuel	Diesel
Gross Power	74 hp (55 kw)
Max Torque	295 lbs ft (400 nm)
Power Measured @	2,400 rpm
Torque Measured @	1,200 rpm
General Specifications
ENGINE POWER HP (KW) (Since 2016)	74 (55)
ENGINE POWER HP (KW) (2017)	74 (55)
ENGINE POWER HP (KW) (2019)	74 (55)
ENGINE POWER HP (KW) (2020)	74 (55)
Engine Power HP (KW) (Since 2021)	74 (55)
Engine Power HP (KW) (2022)	74 (55)
Engine Power HP (KW) (2023)	74 (55)
Engine Power HP (KW) (2024)	74 (55)
Engine Power HP (KW) (2025)	74 (55)
MODEL (Since 2016)	300
MODEL (2017)	300
MODEL (2019)	300
MODEL (2020)	300
OPERATING LOAD LBS. (KG) (Since 2016)	3,000 (1,361)
OPERATING LOAD LBS. (KG) (2017)	3,000 (1,361)
OPERATING WIDTH IN. (CM) (Since 2016)	72 (183)
OPERATING WIDTH IN. (CM) (2017)	72 (183)
OPERATING WIDTH IN. (CM) (Since 2019)	75 (190)
OPERATING WIDTH IN. (CM) (2020)	75 (190)
Operating Width IN. (CM) (Since 2021)	75 (190)
Operating Width IN. (CM) (2022)	75 (190)
Operating Width IN. (CM) (2023)	75 (190)
Operating Width IN. (CM) (2024)	75 (190)
Operating Width IN. (CM) (2025)	75 (190)
Rated Operating Capacity LBS. (KG) (Since 2025)	3,186 (1,445)
RATED OPERATING CAPACITY LBS. (KG) (50%) (Since 2019)	3,186 (1,445)
RATED OPERATING CAPACITY LBS. (KG) (50%) (2020)	3,186 (1,445)
Rated Operating Capacity LBS. (KG) 50% (Since 2021)	3,186 (1,445)
Rated Operating Capacity LBS. (KG) 50% (2022)	3,186 (1,445)
Rated Operating Capacity LBS. (KG) 50% (2023)	3,186 (1,445)
Rated Operating Capacity LBS. (KG) 50% (2024)	3,186 (1,445)
Hydraulic System
Pump Flow Capacity	24 gpm (90 lpm)
Relief Valve Pressure	3,335 psi
Loader
Breakout Force	6,543 lbs (2,968 kg)
Bucket Capacity	1 cu yd (0 cu m)
Bucket Width	75 in (190 cm)
Loader lift capacity with bucket	6,056 lbs (2,747 kg)
Operating Load Rating	3,000 lbs (1,361 kg)
Operating Width	72 in (183 cm)
Tipping Angle	6,369 degrees
Operating Specifications
Alternator Supplied Amperage	95 amps
Chain Box Fluid Capacity - each side	6 gal (23 l)
Cooling System Fluid Capacity	4 gal (16 l)
Engine Oil Fluid Capacity	4 gal (15 l)
Fuel Capacity	27 gal (103 l)
Hydraulic System Fluid Capacity	15 gal (55 l)
Max Speed	12 mph (20 kph)
Operating Speed	7 mph (11 kph)
Operating Voltage	12 volts
Operational Weight	9,288 lbs (4,213 kg)
Tire Size	12 x 16.5
Tires
Standard	12 x 16.5 - 10 PR Xtra Wall Off Road
Transmission
Travel Speed	13 mph (20 kph)
