For Sale: Call for Price
| Stock Number: | 2733406 |
| Machine Location: | ABBOTSFORD, BC |
| More Information: | https://matsquijcb.com/inventory/telehandlers/2020-jcb-560-80+agri-abbotsford-bc-6933630e556e493d3000c4c2/ |
Supplied by HeavyEquipmentData.com →
| Capacities | |
| Diesel exhaust fluid (DEF) tank | 6 gal (21 l) |
| Engine coolant | 6 gal (23 l) |
| Engine Oil | 4 gal (14 l) |
| Fuel Tank | 39 gal (146 l) |
| Hydraulic Tank | 30 gal (112 l) |
| Dimensions | |
| Ground Clearance | 17 in (43 cm) |
| Lift capacity to full height | 6,614 lbs (3,000 kg) |
| Overall Height | 9 ft (3 m) |
| Weight | 23,215 lbs (10,530 kg) |
| Wheelbase | 9 ft (3 m) |
| Width Over Tires | 8 ft (3 m) |
| Electrical System | |
| Battery capacity | 220 Ah |
| Voltage | 12 volts |
| Engine | |
| Aspiration | TCA |
| Bore | 4 in (11 cm) |
| Displacement | 293 cu in (4,801 cu cm) |
| Emissions level | T4F / Stage IV |
| Engine Make | JCB |
| Engine oil service interval hours | 500 |
| Gross Power | 145 hp (108 kw) |
| Max Torque | 413 lbs ft (560 nm) |
| Number of Cylinders | 4 |
| Power Measured @ | 2,200 rpm |
| Stroke | 5 in (14 cm) |
| Torque Measured @ | 1,500 rpm |
| Hydraulic System | |
| 3771 | 260 bar psi |
| Bucket crowd | 3 seconds |
| Dump Time | 3 seconds |
| Extend | 8 seconds |
| Lower Time | 8 seconds |
| Pump Type | Variable |
| Raise Time | 7 seconds |
| Retract | 6 seconds |
| Lift System | |
| Max Forward Reach | 15 ft (4 m) |
| Max Lift Capacity | 13,228 lbs (6,000 kg) |
| Max Lift Height | 26 ft (8 m) |
| Transmission | |
| Lift capacity at full reach | 3,858 lbs (1,750 kg) |
