2004 JCB 456ZX

Name: 2004 JCB 456ZX
Brand: JCB
SKU: 87016831
Price: 1 USD
Availability: OutOfStock

❮

❯

/ Save to Watch List

Apply for Financing

MACHINE SOLD

Auction Info: Starting on 2026-05-06 Click here to place a bid

Ritchie Bros. Auctioneers

Ritchie Bros. Auctioneers Dealer Info

Ritchie Bros. Auctioneers Website

Click here to email Ritchie Bros. Auctioneers.

Click for Phone Number

Machine Info:

Serial Number:	0539177
Machine Location:	MOERDIJK, NLD

Description:

Enclosed Cab, Autoshift, 2450 mm Bucket, 23.5-25 Tires ** Serial Number Mentioned on Registration Document Cannot be Found on Unit ** Romanian Registration Available **

From the manufacturer:

Supplied by HeavyEquipmentData.com →

Bucket
Breakout Force	36,194 lbs (16,417 kg)
Bucket Width	9 ft (3 m)
Dump Clearance at Max Raise	10 ft (3 m)
Dimensions
Dump Clearance at Max Lift	10 ft (3 m)
Fork Tine Length	4 ft (1 m)
Ground Clearance	2 ft (0 m)
Height - Top of Cab	11 ft (3 m)
Hinge Pin - Max Height	14 ft (4 m)
Hinge Pin Max Height	14 ft (4 m)
Length w/ Bucket on Ground	26 ft (8 m)
Length with Bucket on Ground	26 ft (8 m)
Max Lift Height	13 ft (4 m)
Reach at Max Height and Dump	4 ft (1 m)
Reach at Max Lift and Dump	4 ft (1 m)
Wheelbase	11 ft (3 m)
Width Over Tires	9 ft (3 m)
Engine
Aspiration	turbocharged
Displacement	507 cu in (8,300 cu cm)
Engine Model	6CT 8.3C
Max Torque	733 lbs ft (994 nm)
Number of Cylinders	6
Power Measured @	2,200 rpm
Torque Measured @	1,400 rpm
Hydraulic System
Dump Time	1 seconds
Lower Time	4 seconds
Pump Type	twin variable displacement piston pump
Raise Time	6 seconds
Relief Valve Setting	3,625 psi
Operating Specifications
Alternator Supplied Amperage	70 amps
Cooling System Fluid Capacity	11 gal (40 l)
Engine Oil Capacity	5 gal (19 l)
Engine Oil Fluid Capacity	5 gal (19 l)
Front Axle/Diff Fluid Capacity	18 gal (69 l)
Front Diff Fluid Capacity	18 gal (69 l)
Fuel Capacity	85 gal (320 l)
Hydraulic System Fluid Capacity	57 gal (215 l)
Operating Voltage	24 volts
Rear Axle Oscillation	25 degrees
Rear Axle/Diff Fluid Capacity	14 gal (51 l)
Rear Diff Fluid Capacity	14 gal (51 l)
Static Tipping Load - Bucket	33,541 lbs (15,214 kg)
Static Tipping Load - Forks	26,041 lbs (11,812 kg)
Static Tipping Weight	32,265 lbs (14,635 kg)
Transmission Fluid Capacity	9 gal (34 l)
Transmission
Max Speed - Forward	23 mph (38 kph)
Max Speed - Reverse	15 mph (24 kph)
Max Speed Forward	23 mph (38 kph)
Max Speed Reverse	15 mph (24 kph)
Number of Forward Gears	4
Number of Reverse Gears	3
Transmission Type	smooth shift powershift
