For Sale: $17,818.00 USD
Apply for Financing| Hours: | 1 |
| Stock Number: | 0200264146 |
| Machine Location: | MENOMONEE FALLS, WI |
| More Information: | https://yesequipment.com/inventory/aerial+work+platforms/2017-jlg-2632es-menomonee+falls-wi-5d4c6385c162cd2c835f13a2/ |
Supplied by HeavyEquipmentData.com →
| Brakes | |
| Brakes Type | Electric Friction |
| Dimensions | |
| Ground Clearance | 4 in (10 cm) |
| Overall Height | 8 ft (2 m) |
| Overall Length | 91 in (231 cm) |
| Overall Width | 3 ft (1 m) |
| Platform Dimension A | 3 ft (1 m) |
| Platform Dimension B | 8 ft (2 m) |
| Turning Radius | 7 ft (2 m) |
| Wheelbase | 6 ft (2 m) |
| Engine | |
| Battery Amp Hours | 4 x 6V 220 amp-hour |
| Charger Amps | 20 |
| Maximum Ground Bearing Pressure | 90 psi |
| Performance | |
| Drive Speed - Platform Elevated | 1 mph (1 kph) |
| Drive Speed - Platform Lowered | 3 mph (5 kph) |
| Drive System | 24V Electric |
| Gradeability | 25% |
| Hydraulic Pump Type | Fixed Displacement Gear |
| Hydraulic System Fluid Capacity | 1 gal (5 l) |
| Maximum Drive Height | 20 ft (6 m) |
| Operating Weight | 4,635 lbs (2,102 kg) |
| Tire Size | 16 X 5 in |
| Platform | |
| Height of Rails | 4 ft (1 m) |
| Lift Time | 33 seconds |
| Lower Time | 37 seconds |
| Max Platform Height | 4 ft (1 m) |
| Max Working Height | 32 ft (10 m) |
| Platform Capacity - Extension | 250 lbs (113 kg) |
| Platform Capacity - Unrestricted | 500 lbs (227 kg) |
| Platform Railing Height | 26 ft (8 m) |
