John Deere 750J is a crawler dozer designed for grading, earthmoving, site preparation, and general construction work. It is part of John Deere's J Series dozer lineup and is commonly used in road building, land clearing, utility work, and material handling. The 750J features a tracked undercarriage for traction and stability on uneven terrain, with a blade system suited to pushing, leveling, and shaping soil or aggregate. Typical applications include excavation support, backfilling, and finish grading. The model is recognized in the crawler dozer category for its balance of maneuverability, durability, and jobsite versatility in medium-duty earthmoving operations.

Dimensions
Ground Clearance	1 ft (0 m)
Height - Top of Cab	10 ft (3 m)
Length of Track on Ground	9 ft (3 m)
Length w/ Blade	16 ft (5 m)
Width Over Tracks	8 ft (2 m)
Engine
Aspiration	Turbocharged w/ after-cooler
Displacement	414 cu in (6,784 cu cm)
Engine Model	6068H
Gross Power	157 hp (117 kw)
Make	Deere
Max Torque	500 lbs ft (678 nm)
Net Power	145 hp (108 kw)
Number of Cylinders	6
Power Measured @	2,100 rpm
Torque Measured @	1,400 rpm
Hydraulic System
Pump Flow Capacity	38 gpm (144 lpm)
Pump type	Piston
Relief Valve Pressure	3,625 psi
Operating Specifications
Alternator Supplied Amperage	80 amps
Cooling System Fluid Capacity	6 gal (22 l)
Engine Oil Capacity	7 gal (27 l)
Final Drives Fluid Capacity	4 gal (15 l)
Fuel Capacity	98 gal (371 l)
Hydraulic Fluid Capacity	28 gal (106 l)
Operating Voltage	24 volts
Operating Weight	32,585 lbs (14,780 kg)
Standard Blade
Blade Angle (both directions)	24 degrees
Capacity	4 cu yd (3 cu m)
Height	47 in (119 cm)
Width	11 ft (3 m)
Transmission
Max Speed - Forward	6 mph (10 kph)
Max Speed - Reverse	6 mph (10 kph)
Transmission Type	Hydrostatic
Undercarriage
Ground Contact Area	4,488 cu in (73,545 cu cm)
Ground Pressure	7 psi
Number of Shoes per Side	40
Number of Track Rollers per Side	7
Standard Shoe Size	22 in (56 cm)
Track Gauge	6 ft (2 m)
Track Pitch	8 in (19 cm)
