Equipment ↠ John Deere ↠ Crawler Loaders ↠ 2011 John Deere 655C

2011 John Deere 655C For Sale in MT VERNON, IL

Name: 2011 John Deere 655C
Brand: John Deere
SKU: 85663756
Price: 72000 USD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $72,000.00 USD

Apply for Financing

McCoy Construction & Forestry

McCoy Construction & Forestry Dealer Info

McCoy Construction & Forestry Website

Click here to email McCoy Construction & Forestry.

Contact: Anthony Abert

Click for Phone Number

Machine Info:

Serial Number:	LU655CX009102
Stock Number:	305632
Machine Location:	MT VERNON, IL

Description:

CAB, A/C, 22" PADS, AIR SUSPENSION SEAT, GP BKT

Machine Details:

General Specifications
Operators Station	Cab w/ AC
Tracks	Standard Track
Buckets	General Purpose Bkt

From the manufacturer:

Supplied by HeavyEquipmentData.com →

John Deere 655C Crawler Loader is a tracked construction machine designed for material handling, loading, grading, and site preparation. Built with a crawler undercarriage, it provides traction and stability on soft, uneven, or muddy ground. The 655C is commonly used in construction, landscaping, utility work, and general earthmoving applications. It features a front loader bucket and a durable chassis suited for pushing, lifting, and transporting bulk materials. As part of John Deere's crawler loader lineup, the 655C is recognized for its versatility in confined job sites and mixed terrain conditions.

Dimensions
Clearance at Full Height and Dump	9 ft (3 m)
Ground Clearance	1 ft (0 m)
Height - Top of Cab	10 ft (3 m)
Length to Front of Track	14 ft (4 m)
Length with Bucket on Ground	20 ft (6 m)
Reach at Dump Height	4 ft (1 m)
Width to Outside of Tracks	7 ft (2 m)
Engine
Aspiration	Turbocharged
Displacement	405 cu in (6,637 cu cm)
Engine Model	D924T-Ea1
Max Torque	432 lbs ft (586 nm)
Net Power	130 hp (97 kw)
Number of Cylinders	4
Power Measured @	2,000 rpm
Torque Measured @	1,400 rpm
Hydraulic System
Pump Flow Capacity	41 gpm (155 lpm)
Pump Type	Variable displacement piston pump with load sensing proportional pump flow control
Relief Valve Pressure	3,770 psi
Operating Specifications
Alternator Supplied Amperage	55 amps
Breakout Force Bucket	27,675 lbs (12,553 kg)
Bucket Capacity - heaped	2 cu yd (2 cu m)
Cooling System Fluid Capacity	18 gal (68 l)
Engine Oil Capacity	5 gal (20 l)
Final Drive Fluid Capacity - each	9 gal (34 l)
Fuel Capacity	69 gal (261 l)
Hydraulic System Fluid Capacity	34 gal (129 l)
Max Speed	7 mph (11 kph)
Operating Voltage	24 volts
Operating Weight	33,950 lbs (15,399 kg)
Static Tipping Load	23,086 lbs (10,472 kg)
Undercarriage
Ground Contact Area	4,302 cu in (70,497 cu cm)
Ground Pressure	8 psi
Length of Track on Ground	8 ft (3 m)
Number of Shoes per Side	42
Number of Track Rollers per Side	6
Track Gauge	66 in (168 cm)
Track Shoe Width	22 in (56 cm)
