Equipment ↠ John Deere ↠ Excavators ↠ 2012 John Deere 190DW

2012 John Deere 190DW For Sale in Saskatoon, SK

Name: 2012 John Deere 190DW
Brand: John Deere
SKU: 87654029
Price: 119000 CAD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $87,321.00 USD
Converted From: 119,000.00 CAD

Apply for Financing

Korpan Tractor

Korpan Tractor Dealer Info

Korpan Tractor Website

Click here to email Korpan Tractor.

Contact: Main

Click for Phone Number

Machine Info:

Stock Number:	K2251
Machine Location:	SASKATOON, SK

Description:

Hyd. Coupler, Aux. Hyd., 36" Dig & 55" Cleanup Buckets

From the manufacturer:

Supplied by HeavyEquipmentData.com →

Boom/Stick Excavator Option 1
Max Digging Depth	19 ft (6 m)
Max Reach Along Ground	31 ft (10 m)
Boom/Stick Mobile Excavator Option 1
Max Cutting Height	30 ft (9 m)
Max Digging Depth	19 ft (6 m)
Max Loading Height	21 ft (6 m)
Max Reach Along Ground	31 ft (9 m)
Max Vertical Wall Dig Depth	17 ft (5 m)
Shipping Height of Unit	10 ft (3 m)
Shipping Length of Unit	30 ft (9 m)
Boom/Stick Mobile Excavator Option 2
Max Cutting Height	32 ft (10 m)
Max Digging Depth	20 ft (6 m)
Max Loading Height	23 ft (7 m)
Max Reach Along Ground	31 ft (9 m)
Max Vertical Wall Dig Depth	17 ft (5 m)
Shipping Height of Unit	11 ft (3 m)
Shipping Length of Unit	29 ft (9 m)
Bucket
Maximum Bucket Capacity	2 cu yd (1 cu m)
Minimum Bucket Capacity	1 cu yd (1 cu m)
Reference Bucket Capacity	1 cu yd (1 cu m)
Dimensions
Digging Depth	19 ft (6 m)
Digging Reach	31 ft (10 m)
Ground Clearance	1 ft (0 m)
Height - Top of Cab	10 ft (3 m)
Overall Width	8 in (21 cm)
Overall Width - Outriggers Down	11 ft (3 m)
Tail Swing Radius	8 ft (2 m)
Upper Structure Clearance	4 ft (1 m)
Wheelbase	9 ft (3 m)
Engine
Aspiration	turbocharged and intercooled
Displacement	317 cu in (5,195 cu cm)
Engine Model	4HK1X Tier III certified
Net Power	159 hp (119 kw)
Number of Cylinders	4
Power Measured @	2,000 rpm
Operating Specifications
Alternator Supplied Amperage	50 amps
Cooling System Fluid Capacity	6 gal (22 l)
Engine Oil Capacity	6 gal (23 l)
Front Diff Fluid Capacity	3 gal (10 l)
Fuel Capacity	77 gal (290 l)
Hydraulic Pump Flow Capacity	100 gpm (378 lpm)
Hydraulic Pump Type	Variable Axial-Piston
Hydraulic System Fluid Capacity	64 gal (240 l)
Hydraulic System Relief Valve Pressure	4,975 psi
Operating Voltage	24 V
Oscillating Axle Angle	7 degrees
Rear Diff Fluid Capacity	4 gal (14 l)
Tire Size	10.00-20 16 PR
Swing Mechanism
Swing Speed	12 rpm
Swing Torque	29,800 lbs ft (40,403 nm)
Transmission
Max Travel Speed	22 mph (35 kph)
Number of Forward Gears	2
Number of Reverse Gears	2
Transmission Type	Automatic shift
