Equipment ↠ John Deere ↠ Wheel Loaders ↠ 2003 John Deere TC62H

2003 John Deere TC62H For Sale in MT VERNON, IL

Name: 2003 John Deere TC62H
Brand: John Deere
SKU: 84051764
Price: 65000 USD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $65,000.00 USD

Apply for Financing

McCoy Construction & Forestry

McCoy Construction & Forestry Dealer Info

McCoy Construction & Forestry Website

Click here to email McCoy Construction & Forestry.

Contact: Anthony Abert

Click for Phone Number

Machine Info:

Serial Number:	DWTC62H589329
Stock Number:	305850
Machine Location:	MT VERNON, IL

Description:

CAB, A/C, COUPLER, RIDE CONTROL, DUAL DIFF

Machine Details:

General Specifications
Operators Station	Cab w/ AC
Attachments	Quick Coupler
Powertrain	Ride Control
Tires	28L Tires
Booms	Tool Carrier

From the manufacturer:

Supplied by HeavyEquipmentData.com →

Bucket
Breakout Force	27,091 lbs (12,288 kg)
Bucket Capacity - heaped	4 cu yd (3 cu m)
Bucket Capacity - struck	3 cu yd (2 cu m)
Dimensions
Dump Clearance at Max Lift	10 ft (3 m)
Fork Tine Length	4 ft (1 m)
Ground Clearance	1 ft (0 m)
Height - Top of Cab	11 ft (3 m)
Height at Hook Max Reach	7 ft (2 m)
Hinge Pin Max Height	13 ft (4 m)
Hook Height at Max Lift - standard	19 ft (6 m)
Hook Max Reach - standard	12 ft (4 m)
Hook Reach at Max Lift - extended	12 ft (4 m)
Length w/ Bucket on Ground	25 ft (8 m)
Length with out Forks on Ground	26 ft (8 m)
Max Lift Height	13 ft (4 m)
Reach at Max Height and Dump	4 ft (1 m)
Wheelbase	10 ft (3 m)
Width Over Tires	9 ft (3 m)
Engine
Aspiration	Turbocharger with Aftercooler
Displacement	414 cu in (6,784 cu cm)
Engine Model	6068H
Gross Power	172 hp (128 kw)
Max Torque	578 lbs ft (784 nm)
Net Power	160 hp (119 kw)
Number of Cylinders	6
Power Measured @	2,200 rpm
Torque Measured @	1,300 rpm
Hydraulic System
Dump Time	2 seconds
Lower Time	3 seconds
Pump Flow Capacity	55 gpm (208 lpm)
Pump Type	Piston Pump
Raise Time	6 seconds
Relief Valve Setting	3,600 psi
Operating Specifications
Alternator Supplied Amperage	55 amps
Cooling System Fluid Capacity	6 gal (22 l)
Engine Oil Capacity	5 gal (20 l)
Front Diff Fluid Capacity	7 gal (27 l)
Fuel Capacity	70 gal (265 l)
Hydraulic System Fluid Capacity	31 gal (117 l)
Operating Voltage	24 volts
Operating Weight	30,532 lbs (13,849 kg)
Rear Axle Oscillation	26 degrees
Rear Diff Fluid Capacity	6 gal (21 l)
Static Tipping Load - Bucket	21,506 lbs (9,755 kg)
Static Tipping Load - Forks	16,636 lbs (7,546 kg)
Static Tipping Load - Material Handler	11,036 lbs (5,006 kg)
Tire Size	20.5-25
Transmission Fluid Capacity	7 gal (27 l)
Turning Radius	17 ft (5 m)
Transmission
Max Speed Forward	25 mph (39 kph)
Max Speed Reverse	15 mph (24 kph)
Number of Forward Gears	4
Number of Reverse Gears	3
Transmission Type	Power Shift

Dealer Contact Info:

McCoy Construction & Forestry

McCoy Construction & Forestry Dealer Info

McCoy Construction & Forestry Website

Email McCoy Construction & Forestry.

Contact: Anthony Abert

Click for Phone Number
