Brakes
Brakes Type	Wet disc
Dimensions
Front Tread Range	37 in (93 cm)
Ground Clearance	8 in (21 cm)
Height - Top of ROPS/FOPS	7 ft (2 m)
Rear Tread Range	32 in (82 cm)
Tire Size	24x12.00-12
Wheelbase	5 ft (1 m)
Width	45 in (115 cm)
Drive System
Drive	4WD
Engine
Bore	3 in (7 cm)
Displacement	55 cu in (898 cu cm)
Engine Make	KUBOTA
Engine Model	D902
Engine Type	Liquid-cooled 3-cylinder diesel
Gross Power	23 hp (17 kw)
Max Torque	41 lbs ft (56 nm)
Number of Cylinders	3
Power Measured @	3,450 rpm
PTO Power	18 hp (13 kw)
Stroke	3 in (7 cm)
Hydraulic System
Number of Remote Control Valves	2
Pump Flow Capacity	6 gpm (23 lpm)
Relief Valve Pressure	1,790 psi
Operating Specifications
3 Point Hitch Lift Capacity @ 24 inches	684 lbs (310 kg)
3 Point Hitch Type	SAE Category I
Cooling System Fluid Capacity	1 gal (3 l)
Fuel Capacity	7 gal (25 l)
Operating Weight	1,433 lbs (650 kg)
Turning Radius	8 ft (2 m)
Power Take-Off (PTO)
Mid- PTO	Live independent PTO
PTO type	STD (540rpm)
Rear PTO	STD (2500rpm)
Production
Series	BX80 Series
Years Manufactured	2017 -
Transmission
Number of Forward Gears	2
Number of Reverse Gears	2
Transmission Type	Hydrostatic transmission
Travelspeeds(FRWD)Speed range	8 mph (14 kph)
