2017 Liebherr L 514 For Sale in Caorso, Ita

Name: 2017 Liebherr L 514
Brand: Liebherr
SKU: 87706180
Price: 1 USD
Availability: InStock

❮

❯

/ Save to Watch List

Apply for Financing

Auction Pricing

Auction Info: Starting on 2026-05-21

Ritchie Bros. Auctioneers

Ritchie Bros. Auctioneers Dealer Info

Ritchie Bros. Auctioneers Website

Click here to email Ritchie Bros. Auctioneers.

Click for Phone Number

Machine Info:

Hours:	9275
Serial Number:	VATZ1663LZB048118
Machine Location:	CAORSO, ITA

Description:

Enclosed Cab, Air Conditioner, Rear View Camera, Joystick Steering, Roll-Out Bucket, Top Air filter Closing Time: 2026-05-21 08:18:45 AM

From the manufacturer:

Supplied by HeavyEquipmentData.com →

Bucket
Breakout Force	17,310 lbs (7,852 kg)
Bucket Capacity - heaped	2 cu yd (2 cu m)
Bucket Width	8 ft (2 m)
Dump Clearance at Max Raise	9 ft (3 m)
Dimensions
Ground Clearance	1 ft (0 m)
Height - Top of Cab	10 ft (3 m)
Hinge Pin - Max Height	12 ft (4 m)
Length with Bucket on Ground	20 ft (6 m)
Reach at Max Lift and Dump	3 ft (1 m)
Wheelbase	9 ft (3 m)
Engine
Aspiration	Inline engine water-cooled exhaust-turbo charged
Displacement	275 cu in (4,502 cu cm)
Engine Model	D 504 T
Gross Power	98 hp (73 kw)
Number of Cylinders	4
Power Measured @	2,400 rpm
Torque Measured @	1,400 rpm
Hydraulic System
Dump Time	2 seconds
Lower Time	3 seconds
Pump Flow Capacity	30 gpm (115 lpm)
Pump Type	Gear pump
Raise Time	5 seconds
Relief Valve Setting	3,336 psi
Operating Specifications
Alternator Supplied Amperage	65 amps
Engine Oil Fluid Capacity	4 gal (14 l)
Front Axle/Diff Fluid Capacity	3 gal (13 l)
Fuel Capacity	37 gal (140 l)
Hydraulic System Fluid Capacity	28 gal (105 l)
Operating Voltage	12 volts
Operating Weight	17,020 lbs (7,720 kg)
Rear Axle Oscillation	12 degrees
Rear Axle/Diff Fluid Capacity	0 gal (1 l)
Static Tipping Weight	12,511 lbs (5,675 kg)
Tire Size	15.5R25 or 17.5R25
Turning Radius	15 ft (4 m)
Transmission
Max Speed - Forward	19 mph (30 kph)
Max Speed - Reverse	19 mph (30 kph)
Number of Forward Gears	2
Number of Reverse Gears	2
Transmission Type	Stepless hydrostatic travel drive
