The Volvo L150H is a wheel loader designed for material handling, aggregate, construction, and quarry applications. It is part of Volvo Construction Equipment's H-series and is built for loading, stockpiling, truck loading, and general earthmoving tasks. The L150H typically features a fuel-efficient Volvo engine, load-sensing hydraulics, automatic transmission, and a reinforced loader frame for demanding work cycles. Operator comfort, visibility, and service access are key design elements. The model is commonly used with general-purpose, rock, and high-capacity buckets, as well as forks and other attachments. The Volvo L150H is recognized for productivity, durability, and application versatility.

Axles
Axle oil front	12 gal (46 l)
Axle oil rear	15 gal (55 l)
Front	Volvo AWB 40B
Rear	Volvo AWB 40C
Rear axle oscillation	15 degrees
Bucket
Breakout Force	53,077 lbs (24,076 kg)
Dump Clearance at Max Raise	10 ft (3 m)
Dimensions
Ground Clearance	2 ft (1 m)
Height - Top of Cab	12 ft (4 m)
Hinge Pin - Max Height	14 ft (4 m)
Length with Bucket on Ground	29 ft (9 m)
Wheelbase	12 ft (4 m)
Width Over Tires	10 ft (3 m)
Drive System
Torque multiplication, stall ratio	2.09:1
Transmission	Volvo HTL 223
Transport speed, maximum	24 mph (38 kph)
Electrical System
Alternator rating	2280/80 (W/A)
Battery capacity	2 x 170 Ah
Cold cranking capacity	1000 A
Starter motor output	9 hp (7 kw)
Voltage	24 V
Engine
Aspiration	Turbocharged
Displacement	781 cu in (12,802 cu cm)
Engine Model	Volvo D13J
Gross Power	295 hp (220 kw)
Make	Volvo
Net Power	295 hp (220 kw)
Number of Cylinders	6
Power Measured @	1,300 rpm
Torque Measured @	1,000 rpm
General Specifications
Bucket Capacity (Since 2016)	3.5 - 12.4 (2.7 - 9.5)
Bucket Capacity (Since 2017)	4.6 - 18.3 (3.5 - 13.9)
Bucket Capacity (2019)	4.6 - 18.3 (3.5 - 13.9)
Bucket Capacity (Since 2020)	8.4 (6.4)
Bucket Capacity (2021)	8.4 (6.4)
Bucket Capacity (Since 2022)	6.3 (4.4)
Bucket Capacity (Since 2023)	6.3 (4.8)
Bucket Capacity (2024)	6.3 (4.8)
Engine Power (Since 2016)	300 (224)
Engine Power (Since 2017)	295 (220)
Engine Power (2019)	295 (220)
Engine Power (2020)	295 (220)
Engine Power (2021)	295 (220)
Engine Power (2022)	295 (220)
Engine Power (2023)	295 (220)
Engine Power (2024)	295 (220)
Engine type (Since 2016)	D13J
Engine type (2017)	D13J
Engine type (Since 2019)	Volvo D13J
Engine type (Since 2020)	Volvo D13J (Tier 4F)
Engine type (2021)	Volvo D13J (Tier 4F)
Engine type (2022)	Volvo D13J (Tier 4F)
Engine type (2023)	Volvo D13J (Tier 4F)
Engine type (2024)	Volvo D13J (Tier 4F)
Max Dump Height (Since 2016)	9.9 (3)
Max Dump Height (Since 2017)	9.9 (3.0)
Max Dump Height (2019)	9.9 (3.0)
Max Dump Height (Since 2020)	9.8 (3)
Max Dump Height (2021)	9.8 (3)
Max Dump Height (Since 2022)	9.6 (2.9)
Max Dump Height (2023)	9.6 (2.9)
Max Dump Height (2024)	9.6 (2.9)
Operating Weight (Since 2016)	55,320 (25,093)
Operating Weight (2017)	55,320 (25,093)
Operating Weight (Since 2019)	53,130 - 56,440 (24,099 - 25,601)
Operating Weight (Since 2020)	56,320 (25,546)
Operating Weight (2021)	56,320 (25,546)
Operating Weight (2022)	56,320 (25,546)
Operating Weight (2023)	56,320 (25,546)
Operating Weight (2024)	56,320 (25,546)
Hydraulic cycle times (unloaded)
Lift	6 seconds
Lower	4 seconds
Tilt	2 seconds
Total cycle time	12 seconds
Hydraulic System
Engine speed	1,900 rpm
Working pressure	Pump 1 - 29 MPa Pump 2 - 31 MPa Pump 3 - 25 MPa
Operating Specifications
Cooling System Fluid Capacity	15 gal (55 l)
DEF tank capacity	8 gal (31 l)
Engine Oil Fluid Capacity	13 gal (50 l)
Fuel Capacity	97 gal (366 l)
Hydraulic System Fluid Capacity	41 gal (156 l)
Rated Bucket Capacity	4 - 16 cu yd (3 - 12 cu m)
Transmission Fluid Capacity	13 gal (48 l)
Steering System
Articulation angle	37 degrees
Cylinder bore	4 in (10 cm)
Maximum flow	53 gpm (202 lpm)
Rod diameter	2 in (6 cm)
Steering cylinders	2
Stroke	1 ft (0 m)
Working pressure	21 MPa 210 bar
Weights
Operational Weight	46,000 - 52,000 lbs (20,865 - 23,587 kg)
